设备用途:适用于各类袜套贴合防水条电力要求:单相 AC220V，50HZ/60HZ额定功率:1.8KW

气压要求:稳定5kg/cm的气源(不带水气)熔接温度:800”C

升温保护:1组气压开关(风嘴气压低于0.3kg/cm?发热管不升温)

熔接速度:1~18m分钟(数字调控)

操作方式:双脚踏(左脚控上下压轮及剪切两组动作，

右脚控滚轮转动及风枪动作)

风枪规格:25mm双排带孔风咀或一字开口风咀(可选)上压轮规格:25mm*45mm(硅轮)下压轮规格:25*25mm(不锈钢)控制方式:PLC触摸屏控制

滚轮提起高度:0~30mm

电机数量:2组(步进电机)

净重:125KG 毛重:170KG(木箱包装)机架:升降机架

机器尺寸:1200*530*1520mm装箱尺寸:1240*670*1620mm

Feature:

Device Purpose: Suitable for attaching waterproof strips tovarious types of sock coversPower Requirement:Single-phase AC220V, 50HZ/60HZRated Power: 1.8kwAir Pressure Requirement:

Stable air source of 5kg/cm*(without water vapor)Welding Temperature: 800°C

Heating Protection: 1 set of air pressure switch (The heating tube willnot栗 heat up when the air pressure of the air nozzle is lower than0.3kg朧谘旨cm*)

Welding Speed: 1-18m per minute (digitally controlled)Operation Mode: Double foot pedals (The left foot controls the up-and-down pressing wheels and two sets of shearing actions, and the rightfoot controls the rotation of the roller and the action of the hot air gun)Hot Air Gun Specification:25mm double-row perforated air nozzle orlinear opening air nozzle (optional)

Specification of Upper Pressing Wheel:25mm*45mm (Silicone wheel)Specif冪絹治cation of Lower Pressing Wheel: 25*25mm (Stainless steel)Control Mode: Controlled by PLC touch screenLifting Height of the Roller: 0-30mm

Number of Motors: 2 groups (Stepper motors)N.W. (Net Weight): 125KG

G.W.(Gross Weight): 170KG (Packed in a wooden case)Frame: Liftable frame

Machine Dimensions (W*L*H):1200*530*1520mmPackaging Dimensions (W*L*H): 1240*670*1620mm
